RIDER-8 Kids ATV
Technical specification:
Battery : 12V/5Ah
Bore and Stroke : 2.06 x 1.94
Clutch : CVT
Cooling : Air Cool
Displacement (Motor size) : 125cc
engine type : Single Cylinder 4 Stroke
Ignition : CDI
Lubrication System : Pressure Splash
Max HP : 6.7 / 8000 (HP/RPM)
Max Speed : 28 mph
Max torque : 6.9 (N.W/rpm)
Start type : Electric
Compression Ratio : 8.0 : 1
Chassis / Suspension / Brakes
Brake System : Drum Brake (front) / Hydraulic Disk Brake (Rear)
Rims : Steel
Tires Front/Rear : 19 x 7 -8 / 19 x 9.5 -8
Dimensions / Capacities
Engine Oil Capacity : TBA
Fuel capacity : 0.75 Gallon
L*W*H : 60" x 37" x 38"
Max Load : 135 lbs
Min Ground Clearance : 6"
Rider Capacity : 1 person
Seat Height : 24"
Wheel base : 38"
Drive Train
Drive System : Chain Drive
Transmission : Automatic
Bore and Stroke : 2.06 x 1.94
Clutch : CVT
Cooling : Air Cool
Displacement (Motor size) : 125cc
engine type : Single Cylinder 4 Stroke
Ignition : CDI
Lubrication System : Pressure Splash
Max HP : 6.7 / 8000 (HP/RPM)
Max Speed : 28 mph
Max torque : 6.9 (N.W/rpm)
Start type : Electric
Compression Ratio : 8.0 : 1
Chassis / Suspension / Brakes
Brake System : Drum Brake (front) / Hydraulic Disk Brake (Rear)
Rims : Steel
Tires Front/Rear : 19 x 7 -8 / 19 x 9.5 -8
Dimensions / Capacities
Engine Oil Capacity : TBA
Fuel capacity : 0.75 Gallon
L*W*H : 60" x 37" x 38"
Max Load : 135 lbs
Min Ground Clearance : 6"
Rider Capacity : 1 person
Seat Height : 24"
Wheel base : 38"
Drive Train
Drive System : Chain Drive
Transmission : Automatic
Transmission: Automatic
Brand New 70% assembled inside a metal crate. Certified Technician required for Assembly, Prepp, Basic maintenance and all tech issues.
Warranty covers 30 days for replacement parts only. Labor, mechanic and Returns NOT Covered.
Lift gate included Residential included
Shipping insurance include Delivery Appointment Included
